Cryogenic Regulator, Combination Pressure Build/Economizer Pre-Set to 325 PSIG Taylor Wharton

Cryogenic Regulator, Combination Pressure Build/Economizer Pre-Set to 325 PSIG Taylor Wharton

This hardworking cryogenic regulator puts together both the function of pressure building along with economizing. The product is compact and does both jobs effectively. Available in multiple pressures.

• All parts made to work well in extremely low temps, down to -320 Farenheit, or -196 Celsiuscopper alloy

• PTFE seat = positive shut-off down to -320 as well.

• High & economizers = compact size, fit and work in tight spaces

• Made to be interchangeable with existing cryogenic regulator units

• Inlet screen keeps out unwanted materials and debris

• Locknut = keep a fixed screw setting

• Max inlet 550 psig

• Cleaned for oxygen per CGA G-4.1

• Made to be used with argon, CO2, nitrogen, oxygen, LNG

Body --> Brass

Bonnet --> Brass

Seat Disk --> PTFE

Springs --> Stainless Steel

Gaskets -->PTFE & Copper

Diaphragm --> Bronze
